HYDRAULIC FILTRATION
LOW AND MEDIUM PRESSURE FILTERS
Designed as in-line return, pressure or off-line recirculation filtration protecting the most sensitive hydraulic system components. Boasting a robust design and a wide choice of options, the LMP series offers a diverse range of housing models and elements to suit low to high flow rates and maximum circuit protection. LMP filters are available as in-line threaded, in-line multi-ported and flanged connections to integrated into circuit control blocks, manifolds/headers. LMP filters are also available in duplex configurations for continuous filtration without any system service interruptions.
Download
LOW AND MEDIUM PRESSURE FILTERS
CATALOG
PDF | 14.35 MB
Prodotti Correlati
In-line filter
LMP 112-116-118-119-120-122-123 MULTIPORT
Pmax 80 bar, 1160 psi Qmax 175 l/m, 46 gpm.
Inverted low pressure / very high flow rate filter
LMP 950 - 951
Pmax 30 bar, 435 psi Qmax 2400 l/m, 634 gpm.
In-line duplex filter (16 bar), medium flow rate
LMD 400 - 401 - 431
Pmax 16 bar, 232 psi Qmax 600 l/m, 159 gpm.
In-line filter
LMP 210 - 211
Pmax 60 bar, 870 psi Qmax 365 l/m, 96 gpm.
Low pressure / very high flow rate filter in parallel
LMP 952 - 953 - 954
Pmax 25 bar, 363 psi Qmax 4500 l/m, 1189 gpm.
In-line Medium pressure simplex
LDP
Pmax 60 bar, 870 psi Qmax 360 l/m, 95 gpm
In-line Medium pressure duplex filters
LDD
Pmax 60 bar, 870 psi Qmax 360 l/m, 95 gpm.
Medium pressure / high flow rate filter
LMP 430 - 431
Pmax 60 bar, 870 psi Qmax 780 l/m, 206 gpm.
In-line filter
LFEX (Elixir®)
Pmax 16 bar, 232 psi Qmax 300 l/m, 79 gpm.
In-line duplex filter (60 bar)
LMD 211
Pmax 60 bar, 870 psi Qmax 200 l/m, 53 gpm.
Duplex (16 bar), high flow rate, upside down mounting
LMD 951
Pmax 16 bar, 232 psi Qmax 1200 l/m, 317 gpm.
Filter with a large filtration surface, especially suitable for lubrication
LPH 630
Pmax 10 bar, 145 psi Qmax 1600 l/m, 352 gpm.
Low pressure/very high flow rate filter
LMP 900 - 901
Pmax 30 bar, 435 psi Qmax 2000 l/m, 528 gpm.
Medium pressure / high flow rate filter
LMP 400 - 401
Pmax 60 bar, 870 psi Qmax 780 l/m, 206 gpm.
Low pressure / very high flow rate filter in parallel
LMP 902 - 903
Pmax 20 bar, 290 psi Qmax 3000 l/m, 793 gpm.
In-line filter
LMP 110
Pmax 80 bar, 1160 psi Qmax 175 l/m, 44 gpm.
